Description
THE MAINTENANCE PROBLEM…
Modern aircraft, such as the BELL 205, 206, 206L, 212 & 412, have complicated electrical wiring systems containing many different connectors, contacts and terminals, the repair of which require precision tools.
It is not a cost effective use of the time of your technical staff to start from scratch and try to become intimately knowledgeable about which precision tools must be used to repair each electrical connector, contact and terminal when DMC has already performed this task for the BELL 205, 206, 206L, 212 & 412.
AOG TIME CONSTRAINTS. Once the aircraft becomes inoperable because of a connector failure, it is imperative to be able to replace the connector, contact or terminal as quickly as possible to avoid revenue loss due to AOG. The DMC892 kit supplies your staff with both the information and the tools necessary to make this type of repair to the BELL 205, 206, 206L, 212 & 412 in the shortest time possible.
THE DMC SOLUTION…
TOOLING RESEARCH. DMC has already researched the list of connectors for the BELL 205, 206, 206L, 212 & 412 and has identified the most common tools required to maintain the electrical connectors. DMC has cross referenced tools to the connectors, contacts and terminals eliminating costly and time-consuming research which would otherwise have to be performed by your local technicians.
IMMEDIATE AVAILABILITY OF TOOLS AND TECHNICAL INFORMATION.
The DMC892 kit contains the tooling to connector, contact and terminal cross reference information which indicate the particular tool(s) that should be selected to repair a specific connector, contact, or terminal. In addition, the kit also contains illustrated operating instructions for the required tooling.
ALL IN ONE. Since these tools, together with their operating instructions, are contained in a single kit, the connector repair can be made in the shortest time possible, thus permitting a rapid return of your aircraft to service. Tool kit supplied in an environmentally sealed fiberglass case and includes: Name Plate, Foam Pads/Inserts, Contents Charts, Instruction Charts, and Tool Selection Charts.
DMC892 TOOL AND ACCESSORY LIST
6?Crimp Tools
12?Positioners
7 Turret Heads
9 Die Sets
1 In-Service Inspection Gage
15 Metal Insertion Tools
25 Metal Removal Tools
70 Plastic Insertion/Rem Tools
4 Contact gages
2 Unwired Contact Removal Tools
1 Wire Cutter
4 Wire Strippers
1 Die Removal Tool
1 9/64? Hex Wrench
1 Coaxial Cable Strippers
DMC892 CONNECTOR COVERAGE
MANUFACTURER? SERIES
MIL-S-12883 Relays
MIL-C-38999 Series 2 and 3
MIL-C-24308 Rectangular Rack & Panel
MIL-C-26482 Series 2
MIL-T-7928 Insulated/Uninsulated Terminals & Splices
MIL-C-39012 RF Coaxial
MIL-C-81511 Series 2
MIL-C-83723 Series 3
MIL-C-28748 Rack & Panel
MIL-C-5015 3450 Series
MIL-R-6106 Relay Modules
MIL-T-7928 Type 2 Class 1 (Insulated)
MIL-T-81714 Terminal Junctions
Automatic Connector N Series Coax
Collins Radio Microline Series
Deutsch Series SE210 & DS
Hartman Relays
ITT Cannon Series CA-KE, D*MA, DPX2MA & MS-K
Kings Electronics Series BNC, C & TNC
Leach Series JL
Molex Single Side Edge Connector & Coaxial
Precision Connector Design Relays
Walter Kidde Fire Detection Connectors
Winchester Electronics MIL-C-28748 (MRAC)
TOOL KIT CONFIGURATION
Type of Case? Portable/Environmental
Number of Cases 1
Color Yellow
Type of Construction Fiberglass/Aluminum
Application Bell 205, 206, 206L, 214 & 412
Coverage Airframe Connectors -? Terminals size 12 AWG?and Smaller
Coaxial Connectors
Type of Inserts?Unicellular Polyethylene Foam with Die Cut Tool Cavities
